【Scope of application】

It is used to determine the impermeability of various fabrics, such as canvas, medical non-woven materials, coated fabrics, geosynthetics, tarpaulins, tent fabrics, thatch fabrics and rain-proof clothing fabrics, etc.

【Related standards】

GB/T 4744-2013 "Textile Waterproof Performance Testing and Evaluation Hydrostatic Pressure Method"

FZ/T 01004 "Test Method for Water Permeability of Coated Fabrics"

JIS L 1092 "Test Method for Waterproofness of Textile Fabrics"

ISO 811 "Determination of Water Resistance"

ISO1420 "Rubber and Plastic Coated Fabrics—Determination of Water Permeability"

BS EN20811, AATCC127 "Waterproof Hydrostatic Pressure Test"

DIN 53886, ERT120-1 160-0, AFNOR G07-057

【technical parameter】

1. Technical indicators:

2. Water pressure rise rate: 1kpa/min～60kpa/min

3. Working mode: 3 types (pressurization, constant pressure timing, constant pressure timing)

4. Display mode: touch display, touch screen Chinese and English menu type operation

5. Power supply: Ac 220V±10% 50HZ 100W

6. Appearance size of the instrument: 550×400×500mm

7. Weight: 85kg
